单一氘+卤钨混合光源

参考报价￥0 / 套

起订量 0 套 · 价格可议 · 支持定制方案

供货能力30 套/月

发货地河南省郑州市市辖区

更新时间2014/9/29 9:11:19

已有 86 位采购商浏览

规格参数

产品介绍

| 光电测量产品 >> 光源 >> 单一氘+卤钨混合光源

Part Number Description
ASBN-D1-W050F

ASBN-D1-W050M 30W deep UV Deuterium lamp and 50W Tungsten-Halogen (3000 oK / 2000 hours / 900 lumens) light source, 180nm ~ 2.6mm.
w/ 1" UV fused silica doublet & UV protected mirror for focusing TH.
w/ 1" UV fused silica doublet for optimal fiber coupling/monochromator f# matching
w/ regulated power supplies.
F: fiber coupling,
M: monochromator f# matching.
ASBN-D1-W075F

ASBN-D1-W075M 30W deep UV Deuterium lamp and 75W Tungsten-Halogen (3000 oK / 2000 hours / 1400 lumens) light source, 180nm ~ 2.6mm.
w/ 1" UV fused silica doublet & UV protected mirror for focusing TH.
w/ 1" UV fused silica doublet for optimal fiber coupling/monochromator f# matching
w/ regulated power supplies.
F: fiber coupling,
M: monochromator f# matching.
ASBN-D1-W100F-H
ASBN-D1-W100F-L

ASBN-D1-W100M-H
ASBN-D1-W100M-L
30W deep UV Deuterium lamp and 100W Tungsten-Halogen light source, 180nm ~ 2.6mm.
w/ 1" UV fused silica doublet & UV protected mirror for focusing TH.
w/ 1" UV fused silica doublet for optimal fiber coupling/monochromator f# matching
w/ regulated power supplies.
H: High color temperature (3400 oK / 50 hours / 3000 lumens)
L: Low color temperature (3000 oK / 2000 hours / 2000 lumens)
F: fiber coupling,
M: monochromator f# matching.
ASBN-D1-W150F

ASBN-D1-W150M
30W deep UV Deuterium lamp and
